High Capacity Lithium Battery Recharge Li Ion Battery For Measuring
Instruments
Model: 14.4V 2100mAh
Specification: 20mmX60mmx90mm
Features: effective discharge rate ≥75% under -40°C working
environment, polymer square low temperature lithium battery, charge
cutoff voltage 16.8V, discharge cutoff voltage 10V, working current
0.5A, maximum working current 2A
Applications: Measuring instruments, meteorological instruments,
polar surveys
| | Number | HY00043 |
| Version | A0 |
HYLF/14.4/2.1-001 Battery pack specification | Date | 2019-5-7 |
| 1．Basic characteristics | Product picture |
Product name | Low temperature lithium battery | Soft pack laser welding assembly method
Low temperature work protection board
-40℃-55℃Ambient operating temperature: -40℃-55℃
40℃,0.2C10.0V,70%.Working characteristics: Under the condition of
low temperature 40 °C, the current is discharged to 10.0V at 0.2C,
and the effective discharge rate is not lower than 70% of the
normal temperature capacity.
|
product code | HYLF/14.4/2.1-001 |
| L x W x H | 20mmX60mmx90mm |
| Rated voltage | 14.4VSeries structure |
| Rated Capacity | 2100mAh |
| Serialization | 4S |
Internal resistance | ≤100mΩ |
| Discharge cutoff voltage | 10.0V |
Shell color
□ Matt black □ Bright gray □ Fruit green + bright gray (two colors) ☑ Black
Charging and discharging interface □ Wall terminal □ Anderson □ Air plug □ Positive and negative lines ☑Hardware contact
|
| Charging protection voltale | 16.8V |
Max.charging voltage | 17V |
Max. charging current | 1A |
Maximum discharge current | 2A |
Peak current | 5±3A 2S |
Rated discharge current | 0.5A |
| Charging method | CC/CV |
|
weight | 99g |
Operating temperature
| Charging | 0～45℃ |
Discharge | -40～55℃ |
60-80%SOC , 2 Storage temperature 60-80% SOC storage, need to
recharge every 2 months |
-10～35℃ |
C1 Cycle life Cycle life | 500 Times |
| price | RMB:¥ 00.00 | |
Delivery period | 25 Working day | |
FAQ
Q1: Are you battery manufacturer or simply trading company?
Re: We are battery manufacturer, and we sincerely welcome you to
visit our factory!
Q2: How do you make sure the quality?
Re: We will do the following works before assembling the pack:
a. Select capacity, same capacities cells for one pack
b. Measure the voltage, same voltage cells for one pack(difference
is under 0.02v per cell)
c. Measure the inner resistance,same IR cells for one pack
(difference is under 1m Ohm)
All above steps are very strict to make sure the pack performance
is perfect.
Q3: What battery packs do you have ?
Re: Our main productus are 18650 battery pack, e-bike battery,
lifepo4 storage battery, polymer battery, or any customized battery
projects.
Q4: Do you accept OEM/ODM for battery?
Re: yes, please don’t hesitate to contact our sales team for more
details.
